Biscuits type metal detector is with unique design of pneumatic retracting band type rejecter to prevent the product from being disordered. Biscuits type metal detector is widely used for different biscuits and sweets production line.
*Advantages on Biscuits Type Metal Detector：：
Biscuits type metal detector is with unique design of pneumatic retracting band type rejecter to prevent the product from being disordered.
Biscuits type metal detector is widely used for different biscuits and sweets production line.
*Biscuits Type Metal Detector Specifications:
|
Model |
IMD-B |
|||||||
|
Specifications |
60 |
70 |
80 |
90 |
100 |
110 |
120 |
|
|
Detection Width |
600mm |
700mm |
800mm |
900mm |
1000mm |
1100mm |
1200mm |
|
|
Detection Height |
50~200mm |
|||||||
|
Sensitivity |
Fe |
≥Φ0.6mm |
||||||
|
SUS304 |
≥Φ1.2mm |
|||||||
|
Belt Width |
560mm |
660mm |
760mm |
860mm |
960mm |
1060mm |
1160mm |
|
|
Conveyor Belt |
Food grade PU |
|||||||
|
Belt Speed |
15m/min (Variable speed optional) |
|||||||
|
Rejecter Mode |
Pneumatic retracting band type |
|||||||
|
Power Supply |
AC220V (Optional) |
|||||||
|
Main Material |
SUS304 |
|||||||
*Note:
1. The technical parameter above namely is the result of sensitivity by detecting only the test sample on the belt. The sensitivity would be affected according to the products being detected, working condition and speed.
2. Requirements for different sizes by customers can be fulfilled.
