Competitive price Good sensitivity and stability
*Product Introduction:
Competitive price
Good sensitivity and stability
*Parameter
| Model |
TXE-1815 |
TXE-2815 |
TXE-3815 |
|
| X-ray Tube |
150W/210W/350W Optional |
|||
| Inspection Width |
200mm |
300mm |
400mm |
|
| Inspection Height |
150mm |
|||
| Best Inspection Ability |
Stainless steel ball Φ0.3mm Stainless steel wire Φ0.3*2mm Glass/Ceramic ball Φ1.0mm |
|||
| Conveyor Speed |
10-60m/min |
|||
| O/S |
Windows |
|||
| Protection Method |
Soft curtain |
|||
| X-ray Leakage |
< 1 μSv/h |
|||
| IP Rate |
IP65 for tunnel |
|||
| Working Environment | Temperature |
0~40℃ |
||
| Humidity |
30~90%, no dew |
|||
| Cooling Method |
Industrial air conditioning |
|||
| Reject Mode |
Sound and light alarm, belt stops (Rejecter optional) |
|||
| Air Pressure |
0.8Mpa |
|||
| Power Supply |
0.8kW |
|||
| Main Material |
SUS304 |
|||
| Surface Treatment |
Brushed SUS |
|||
*Note
The technical parameter above namely is the result of sensitivity by inspecting only the test sample on the belt. The actual sensitivity would be affected according to the products being inspected.
